Technical documentation for Ethereum wallet integration with Nillion using EIP-712 signatures and DIDs.

Overview​

Nillion integrates with Ethereum wallets via MetaMask to create passwordless authentication. Ethereum addresses are transformed into did:ethr: format DIDs through EIP-712 typed data signing.

Key Components:

• DID Format: did:ethr:<ethereum_address>
• Signing Standard: EIP-712 typed data
• SDK: @nillion/nuc handles DID generation
• Client Library: viem for Ethereum interactions
• Storage: React state (runtime), localStorage (tokens), NilDB (profiles)

Authentication Flow​

MetaMask Connection → DID Generation → Subscription Check
→ Token Generation → Profile Registration → Storage

Files:

• src/context/NillionContext.tsx - Wallet/signing logic
• src/hooks/useInitializeSessionMutation.ts - New session flow
• src/hooks/useLoginMutation.ts - Existing session restoration
• src/context/AuthFlowManager.tsx - Flow orchestration

1. DID Generation​

DIDs are generated by the Nillion SDK, not manually constructed.

// Create signer from Web3 wallet
const nucSigner = Signer.fromWeb3({
  getAddress: async () => account,  // MetaMask address
  signTypedData: async (domain, types, message) => {
    return walletClient.signTypedData({...});
  },
});

// Generate DID
const did = await nucSigner.getDid();
// Result: { didString: "did:ethr:0x742d35Cc6634C0532925a3b844Bc9e7595f0bEb" }

Location: src/context/NillionContext.tsx (lines 72-101)

2. MetaMask Signing​

EIP-712 signatures occur in the signTypedData callback passed to Signer.fromWeb3().

signTypedData: async (domain, types, message) => {
  const primaryType = Object.keys(types).find(k => k !== "EIP712Domain");

  // Handle chain switching if needed
  const domainChainId = Number(domain?.chainId);
  if (domainChainId !== activeChainId) {
    await metaMaskProvider.request({
      method: "wallet_switchEthereumChain",
      params: [{ chainId: `0x${domainChainId.toString(16)}` }],
    });
  }

  // Sign via viem
  return walletClient.signTypedData({
    account,
    domain,
    types,
    primaryType,
    message,
  });
}

Signing Triggers:

• Root token generation (refreshRootToken())
• Invocation token creation (signAndSerialize(signer))
• Builder profile registration

Location: src/context/NillionContext.tsx (lines 74-98)

3. EIP-712 Payload Structure​

The Nillion SDK (@nillion/nuc) determines the exact EIP-712 structure. The application receives and passes this payload to MetaMask.

Inferred Structure (based on standard usage):

// Root Token Generation
{
  domain: {
    name: "Nillion",
    version: "1",
    chainId: 1 | 11155111  // Mainnet or Sepolia
  },
  types: {
    EIP712Domain: [...],
    Token: [
      { name: "subscriber", type: "address" },
      { name: "service", type: "string" },
      { name: "nonce", type: "uint256" }
    ]
  },
  message: {
    subscriber: "0x742d35Cc...",
    service: "nildb",
    nonce: 123
  }
}

// Invocation Token
await Builder.invocationFrom(rootToken)
  .audience(node.id)
  .command(NucCmd.nil.db.root)
  .signAndSerialize(signer);  // Triggers EIP-712 signing

Supported Chains:

• Mainnet (chainId: 1)
• Sepolia (chainId: 11155111)

4. Token Architecture​

Token Hierarchy​

Root Token (Subscriber Identity)
  └─ Invocation Tokens (Per-Operation)
       ├─ Node-specific (audience: did:key:node_id)
       └─ Command-specific (NucCmd.nil.db.*)

Root Token​

• Purpose: Proves subscription to Nillion
• Generation: Nilauth service validates signature, returns token
• Format: Base64URL-encoded JWT
• Storage: localStorage as nillion_rootToken

Invocation Tokens​

• Purpose: Authorize specific operations on specific nodes
• Generation: Client-side via Builder.invocationFrom(rootToken)
• Audience: Individual node DIDs (did:key:z6Mk...)
• Storage: localStorage as nillion_nildbTokens (JSON object)

// Generate invocation token
const invocation = await Builder.invocationFrom(rootToken)
  .audience(node.id)                 // Target node
  .command(NucCmd.nil.db.root)       // Authorized operation
  .signAndSerialize(signer);         // EIP-712 sign

Location: src/hooks/useInitializeSessionMutation.ts (lines 39-57)

5. Storage & Persistence​

Client-Side Storage​

React State (Runtime):

{
  signer: NucSigner,
  did: "did:ethr:0x...",
  wallets: {
    isMetaMaskConnected: true,
    metaMaskAddress: "0x..."
  }
}

localStorage (Persistent):

localStorage.setItem("nillion_rootToken", "eyJhbGci...");
localStorage.setItem("nillion_nildbTokens", JSON.stringify({
  "did:key:node1": "eyJhbGci...",
  "did:key:node2": "eyJhbGci...",
  "did:key:node3": "eyJhbGci..."
}));

NilDB Storage​

Builder Profiles:

{
  did: "did:ethr:0x742d35Cc6634C0532925a3b844Bc9e7595f0bEb",
  name: "Demo Builder"
  // Encrypted with Blindfold, replicated across 3 nodes
}

Location: src/hooks/usePersistedConnection.ts, src/hooks/useInitializeSessionMutation.ts

6. Network Architecture​

Endpoints​

// Nilauth (Authentication Service)
https://nilauth.sandbox.app-cluster.sandbox.nilogy.xyz

// NilDB Nodes (Data Storage)
https://nildb-stg-n1.nillion.network
https://nildb-stg-n2.nillion.network
https://nildb-stg-n3.nillion.network

// Nilchain RPC (Internal to SDK)
http://rpc.testnet.nilchain-rpc-proxy.nilogy.xyz

Client Architecture​

Browser
  ├─ MetaMask (EIP-712 signing)
  ├─ Nillion SDK (DID generation, tokens)
  ├─ React App (UI, state management)
  └─ HTTP Requests → Nillion Network
       ├─ Nilauth (subscription check, root token)
       └─ NilDB Nodes (profile read/write)

Location: src/config.ts

7. Verification​

All verification happens server-side on the Nillion Network.

Nilauth Service:

• Validates EIP-712 signatures on root tokens
• Checks subscription status
• Returns signed root tokens

NilDB Nodes:

• Verify invocation token signatures
• Validate token audience (matches node DID)
• Authorize commands (NucCmd permissions)

What Gets Verified:

• EIP-712 signature validity
• DID format (did:ethr:0x...)
• Subscription status
• Token authenticity
• Token audience/commands

8. Complete Flow Examples​

New Session (First-Time Login)​

// 1. Connect MetaMask
const account = await metaMaskProvider.request({
  method: "eth_requestAccounts"
});

// 2. Generate DID
const signer = Signer.fromWeb3({...});
const did = await signer.getDid();
// Result: "did:ethr:0x742d35Cc6634C0532925a3b844Bc9e7595f0bEb"

// 3. Check subscription
const subscription = await nillionClient.fetchNodeSubscriberInfo(did.didString);

// 4. Generate root token (triggers EIP-712 signature)
const rootToken = await nillionClient.refreshRootToken({
  signer,
  service: "nildb"
});

// 5. Generate invocation tokens (one per node)
const invocations = await Promise.all(nodes.map(node =>
  Builder.invocationFrom(rootToken)
    .audience(node.id)
    .command(NucCmd.nil.db.root)
    .signAndSerialize(signer)
));

// 6. Register builder profile
await nillionClient.createProfile({
  auth: { invocations },
  blindfold: { operation: "store" }
});

// 7. Store tokens
localStorage.setItem("nillion_rootToken", rootToken);
localStorage.setItem("nillion_nildbTokens", JSON.stringify(invocations));

Existing Session (Returning User)​

// 1. Connect MetaMask
const account = await metaMaskProvider.request({
  method: "eth_requestAccounts"
});

// 2. Restore DID from signer
const signer = Signer.fromWeb3({...});
const did = await signer.getDid();

// 3. Load tokens from localStorage
const rootToken = localStorage.getItem("nillion_rootToken");
const nildbTokens = JSON.parse(localStorage.getItem("nillion_nildbTokens"));

// 4. Validate by reading profile
const profile = await nillionClient.readProfile({
  auth: { invocations: nildbTokens }
});

// 5. Restore state
setState({ signer, did: did.didString, wallets: {...} });

Location:

• New: src/hooks/useInitializeSessionMutation.ts
• Existing: src/hooks/useLoginMutation.ts

9. DID Usage Patterns​

As Identity​

// Subscription lookup
const info = await nillionClient.fetchNodeSubscriberInfo(
  "did:ethr:0x742d35Cc6634C0532925a3b844Bc9e7595f0bEb"
);

// Profile operations
await nillionClient.createProfile({ /* DID embedded in auth */ });
const profile = await nillionClient.readProfile({ /* ... */ });

As Namespace​

// Storage key
{
  did: "did:ethr:0x742d35Cc...",  // Primary key
  name: "Demo Builder",
  // ... other fields
}

As Cryptographic Proof​

// Token claims
{
  subscriber: "did:ethr:0x742d35Cc...",
  // Signature proves control of Ethereum address
}

10. Error Handling​

Chain Mismatch​

// Automatically switch chains
if (domainChainId !== activeChainId) {
  await metaMaskProvider.request({
    method: "wallet_switchEthereumChain",
    params: [{ chainId: hex }],
  });
}
// Fallback: attempt signature anyway

Duplicate Registration​

// NilDB returns 400 on duplicate profile
if (error.code === 400 && error.message.includes("DuplicateEntry")) {
  // Gracefully continue - profile already exists
}

Token Expiration​

// Refresh root token
const newRootToken = await nillionClient.refreshRootToken({
  signer,
  service: "nildb"
});

Technical Requirements​

Browser Requirements:

• MetaMask installed
• Active Nillion subscription
• Supported Ethereum chain (Mainnet or Sepolia)

Network Access:

• CORS-enabled endpoints
• No direct RPC interaction (handled by MetaMask/SDK)

Security:

• All signatures occur in MetaMask (user approval required)
• Tokens stored client-side (localStorage)
• Profiles encrypted with Blindfold in NilDB

Key Takeaways​

1. SDK-Driven: Nillion SDK handles DID generation, payload construction, and cryptographic operations
2. Client-Side Flow: Entire authentication process runs in browser
3. Server-Side Verification: Signature validation occurs on Nillion Network backend
4. Token Hierarchy: Root token → invocation tokens → authorized operations
5. EIP-712 Standard: Ethereum-native signing for wallet integration
6. Storage Strategy: Runtime (React state), persistent (localStorage), distributed (NilDB)

Codebase: https://github.com/geniusyinka/nillion-metamask-login
Network: Nillion Testnet
Chains: Ethereum Mainnet (1), Sepolia (11155111)
